Shuays Mini

Shuays Mini is the most compact fixture in the Shuays line, designed for applications requiring maximum discretion and durability.
With its small dia of 38mm, it is perfectly suited for subtle installation in concrete, wood decking, or even submerged in water features due to its superior IP68 rating.
The Mini delivers focused accent illumination (1W/3W) with high-CRI color quality, making it an excellent choice for detailed, low-glare lighting in wet or high-traffic environments.

Enquire Now

Wattage

1W / 3W

Lumen

90 lm - 270lm

Beam Angle

8°/ 15°/ 30°/ 45°/ 60°

Cut out

N/A

IP rating

IP 68

Submersible Rating

IP68 rating ensures full protection against prolonged submersion, ideal for fountains, ponds, or areas prone to heavy flooding.

Extreme Impact Resistance

IK08 rating confirms its ability to withstand significant physical impact, essential for ground fixtures.

Low-Voltage Safety

Operates exclusively on Remote DC24V, prioritizing safety and simplifying compliance in complex installations.

Size

Wattage

Lumens

CCT

CRI

Beam Angle

Model Name	Model No	Size	Wattage	Lumens	CCT	CRI	Beam Angle	IP Rating	Accessories	Dimming Option	Specssheet	2D	3D	Installation Manual
Shuays Mini	3050	Dia 38 x H 85mm	3	270	3000	92	60	IP68	NA	Non Dim/Triac Dim/Analog Dim/DALI Dim/DMX	Download	Download	Download	Download
Shuays Mini	3050	Dia 38 x H 85mm	3	270	3000	92	45	IP68	NA	Non Dim/Triac Dim/Analog Dim/DALI Dim/DMX	Download	Download	Download	Download
Shuays Mini	3050	Dia 38 x H 85mm	3	270	3000	92	30	IP68	NA	Non Dim/Triac Dim/Analog Dim/DALI Dim/DMX	Download	Download	Download	Download
Shuays Mini	3050	Dia 38 x H 85mm	3	270	3000	92	15	IP68	NA	Non Dim/Triac Dim/Analog Dim/DALI Dim/DMX	Download	Download	Download	Download
Shuays Mini	3050	Dia 38 x H 85mm	3	270	3000	92	8	IP68	NA	Non Dim/Triac Dim/Analog Dim/DALI Dim/DMX	Download	Download	Download	Download
Shuays Mini	3050	Dia 38 x H 85mm	1	90	3000	92	60	IP68	NA	Non Dim/Triac Dim/Analog Dim/DALI Dim/DMX	Download	Download	Download	Download
Shuays Mini	3050	Dia 38 x H 85mm	1	90	3000	92	45	IP68	NA	Non Dim/Triac Dim/Analog Dim/DALI Dim/DMX	Download	Download	Download	Download
Shuays Mini	3050	Dia 38 x H 85mm	1	90	3000	92	30	IP68	NA	Non Dim/Triac Dim/Analog Dim/DALI Dim/DMX	Download	Download	Download	Download
Shuays Mini	3050	Dia 38 x H 85mm	1	90	3000	92	15	IP68	NA	Non Dim/Triac Dim/Analog Dim/DALI Dim/DMX	Download	Download	Download	Download
Shuays Mini	3050	Dia 38 x H 85mm	1	90	3000	92	8	IP68	NA	Non Dim/Triac Dim/Analog Dim/DALI Dim/DMX	Download	Download	Download	Download
